InnoTek Air HumidiFlex System
IAHS: The Future of Advanced Dehumidification Technology
The InnoTek Air HumidiFlex System (IAHS) represents the next generation of Advanced Dehumidification Technology. By decoupling the dehumidification process from standard cooling, the IAHS provides North American partners with the precision required to manage modern indoor environments.
Utilizing our patented bypass geometry and Advanced Dehumidification Technology, this system eliminates the industry “blind spot” where moisture removal was once an uncontrollable byproduct. Now, manufacturers and master dealers can offer total environmental control through a scalable, software-driven licensing model.
The Missing Link: IAHS HumidiFlex
The HumidiFlex System (IAHS) is a breakthrough upgrade that transforms your existing central split-type cooling system (or new equipment) into a high-performance, precision-controlled dehumidifier. It is the missing link between basic cooling and intentional environmental science.
By bypassing the air, we finally control the leaving dewpoint intentionally, rather than leaving dehumidification as an “uncontrollable byproduct.” It is the smarter, more cost-effective way to achieve perfect indoor comfort while eliminating the need for standalone hardware.
Empowering The Equalizer
To solve a massive blind spot, you need a compensator. We call the forward-thinking professional The Equalizer. We don’t just provide equipment; we empower the professional with a combination of specialized knowledge and high-performance tools.
Through the IAHS, we give the technician or engineer a Performance Monopoly. By combining field experience with a mastery of psychrometrics and our Python-driven logic, The Equalizer differentiates themselves by solving the complex moisture problems others don’t even see.
The Strategy: Localized “License to Build”
The time for expensive, slow-to-ship “black box” hardware is over. Our Open Architecture Philosophy is designed for the modern market, prioritizing easy in-house manufacturing anywhere in the world.
We are currently bridging the gap in North America and the surrounding islands, where humidity is relentless and logistical costs are a major hurdle.
The Blueprint Model: We provide the “Brain”—the custom DMAC controller and the engineering blueprints.
Simple In-House Assembly: Our process is designed for ease. You build and assemble the hardware in your own facility using standard, locally sourced components.
No Logistical Friction: By manufacturing locally, you bypass the nightmare of international shipping and import costs.
Our True Purpose
We aren’t just selling a piece of equipment; we are giving you the tools to simplify the science and return to our trade’s true purpose: True Comfort and Total Environmental Control.
Every HumidiFlex Comes Complete With:
- Inline Fan – engineered for optimal airflow and efficiency
- Dehumidification Mixed Air Controller (DMAC) – the intelligent control hub
- Integrated Sensors – delivering realtime precision monitoring
Three Intelligent Modes for Any Need
| Mode | Purpose | Benefit |
|---|---|---|
Balances cooling and dehumidification. |
Ideal for everyday comfort. | |
Prioritize moisture removal and can be install with several HVAC system. |
Ideal for building your own dehumidifier. | |
Dynamically adjusts in the delivery air of an existing cooling unit. |
Best for variable conditions |
Each mode uses a unique algorithm and control sequence to maximize results, whether your priority is comfort, moisture control, or application flexibility.
How it Works:
Powered by our advanced Bypass Technology and the Dehumidifier Mixed Air Controller (DMAC) with integrated sensors, HumidiFlex ensures optimal performance in virtually any environment.
The secret is the bypass. The system diverts a portion of warm, humid intake air around the main evaporator coil, cooling it to a much lower temperature than standard AC operation. This process maximizes condensation, removing significantly more moisture from the air.
Configured by a specialist, the DMAC automatically adapts to varying loads and system designs, giving end users a flexible, low-
DMAC’s user interface empowers professionals to quickly tailor the HumidiFlex System to any home’s or unique HVAC setup. Here are some of the key configurations:
- Mode Selection: Choose from three distinct operating modes (TCM, MDM, ADMD).
- System Type: Select between an air conditioner or a heat pump. If you select a heat pump, the DMAC prompts you to specify whether the reversing valve is active on cooling or heating, ensuring seamless integration.
- Component Matching: The controller asks for the type of condenser (single-stage, dual-stage, or inverter) and the type of thermostat (single or dual-stage). This guarantees the DMAC operates in perfect sync with the existing equipment.
By allowing this level of customization, the DMAC ensures that every HumidiFlex System installation is not just effective but is also expertly tailored for maximum efficiency and homeowner satisfaction.
This is more than a product; it’s a professional tool for creating a superior comfort experience.
Design Criteria & Why it Matters:
There are two critical design criteria that are essential for correct SIZING and PERFORMANCE. These are detailed in the Installation Manual and Design Manual. These manuals will guide you through:
- Correct performance and size selection.
- Control wiring integration.
- Understanding your existing equipment for seamless compatibility.
Correct sizing and installation are the first steps to unlocking the full potential of the HumidiFlex System. When properly configured, it delivers:
- Maximum moisture control without sacrificing cooling performance.
- Lower installation costs compared to standalone dehumidifiers.
- Professional-
grade precision for HVAC specialists. - Flexible integration with a wide range of central split
type systems
How it is Installed:
There are two installation configurations:
- Return-side Installation
- Supply-side Installation
For optimal performance and reliability, every installation must follow these core principles:
- Bypass Fan Positioning : The bypass fan must draw air from the intake side of the indoor coil and deliver it to the air stream after it exits the coil.
- Inline Fan Arrangement: The inline fan must be installed in series with the indoor system fan — never bypassing it.
- System Start-
Up Protocol: Each time a technician starts the system, begin with the unit in the OFF position, then test the system to ensure it operates as it would on a normal day before enabling dehumidification functions.
The Ultimate Dehumidification Upgrade
The HumidiFlex System (IAHS) is a game-changer. It’s a simple, cost-effective upgrade that transforms your existing air conditioner into a powerful, high-performance dehumidifier. Forget about buying a separate, bulky dehumidifier unit. The HumidiFlex System works with the equipment you already have, saving you money and space.
The DMAC and HumidiFlex System delivers unmatched performance at the lowest cost on the market. With this system, precise humidity control is finally within your reach.
RH Vs. DP being a unique feature offering a improve critical control option.
A/C Vs. Dehumidifier
- Dehumidifiers are very expensive. They also have a very high operating cost compared to A/Cs.
- We significantly reduce costs by using inexpensive off-the-shelf A/Cs to dehumidify instead of expensive custom-made equipment.
- IAHS excels at maintaining humidity levels between 45% and 55%.
Dehumidification
- Most dehumidifiers use "condenser reheat". Their performance is rated at AHAM, which is 80°F and 60% RH. This can be misleading when rating performance.
- We significantly reduce costs by using inexpensive off-the-shelf A/Cs to dehumidify instead of expensive custom-made equipment.
- You can combine IAHS with most HVAC brands and build your own dehumidifiers at a fraction of the cost.
- Our ByPass Dehumidifier, when set to TBD Mode, converts the A/C into a highly efficient dehumidifier.
HumidiFlex System Vs. Stand Alone Dehumidifiers
Here’s how the HumidiFlex System stacks up against traditional whole-house dehumidifiers:
- Adaptive Performance: Unlike other dehumidifiers with fixed performance, HumidiFlex System ‘s adaptive capability allows it to dynamically adjust to changing conditions, consistently delivering optimal dehumidification.
- Greater Capacity: The HumidiFlex System, when integrated with a central cooling system, provides 5 to 6 times the dehumidification capacity of a typical whole-house dehumidifier.
- Solving the Root Problem: Standard dehumidifiers often act as a band-aid, compensating for the uncomfortable overcooling that many AC systems cause. The HumidiFlex System, on the other hand, solves the problem at its source by giving you perfect control over your central cooling unit’s dehumidification behavior.
- Energy Efficiency: Many dehumidifiers use a reheat process to warm the air after dehumidifying, which is an inefficient cycle of cooling and then reheating. This is often necessary to compensate for overcooling. The HumidiFlex System eliminates this need, resulting in significant energy savings and a more comfortable environment without the energy trap of reheating.
Why is IAHS So Effective?
Unlike conventional dehumidification systems that often struggle to deliver consistent results, the IAHS is engineered with a singular focus: maximizing efficiency and performance. Rather than relying on complex formulas or theoretical projections, we highlight one powerful, easy-to-understand metric – the dehumidification ratio.
This ratio reveals how much moisture the IAHS removes per unit of energy consumed, and the difference is dramatic. Compared to standard cooling-based methods, IAHS extracts significantly more water from the air, making it a game-changer in humidity control.
No guesswork. Just results. By measuring the actual weight of water removed (in pounds), you get a clear, quantifiable view of the system’s superior performance – even as ambient temperatures shift. It’s not about complicated math; it’s about real-world impact you can see and measure.
Try it for yourself. On mild days caused by short cycling, you’ll witness up to 10 times more moisture removal than traditional systems. It’s that simple, and that powerful.
All backed by real-world testing using simple, observable water weight. No complex calculations or lab tools required.
The DMAC ability to control cycling is an effective feature, increasing the cooling unit to dehumidify up to 10 times more.
Why invest towards a standalone, less powerful dehumidifier when the HumidiFlex System can do more with less operating and initial investment cost?
It’s a simple, smart investment for superior comfort and lower energy bills.
